XHORSE MULTI PROG MULTI-PROG PROGRAMMER ECU GEARBOX PROGRAMMER - XDMPG0GL

Xhorse XDMPG0GL Multi Prog Programmer ECU Gearbox Programmer

The XDMPG0GL Multi-Prog ECU Programmer is a versatile tool meticulously designed by Xhorse to access and modify crucial data stored in a vehicle's Engine Control Unit (ECU) and Transmission Control Unit (TCU). From engine maps to transmission parameters and immobilizer settings, the XDMPG0GL ECU Programmer empowers users with unprecedented control and customization.

PN: XDMPG0GL
Software: V1.2.0.0, update online
Firmware: V1.2.1 update online
Database version: V25
Lifetime free update online.
Language: English, Chinese

Xhorse MultiProg Feature:
1.Update version of VVDI Prog programmer
2. Free software and firmware update timely.
3. Read, Write and Clone ECU
4. Read, Write and Clone Gearbox TCU
5. Read EEPROM, ECU, MCU
6. Read and Write Bosch ECU ISN with new Bosch ecu adapter
7. Supports Checksum correction for some EDC16/EDC17 ECUs (more to come)
8. Get free BMW ISN read function and NEC, MPC, Infineon etc chip continously update service
9. With built-in free MQB48 license. Bind Multi-prog and VVDI2 (full version) or key tool plus to the same Xhorse app account to use MQB48 NEC35XX function.
10. NEW! Add VAG MQB RH850 dashboard processor (need seperate RH850 cable for multiprog)

Other Features:

Support R&W lots of chips, include MC9S08 series, MC68HC(9)12series, MC9S12series, V850series, H8Xseries, R8Cseries, PCF79XXseries and most eeprom chips etc .
Support chip data verify, checkblank function
Support data file compare function
Free Pin code calculation service by Dump for various models
Support Read and Write BMW N20, N55 ECU (show ISN directly)
Stable Read and Write MC9S12XE series chips (5M48H/ 1N35H/ 2M53J/ 3M25J etc.)
Support renew PCF79XX remote, currently support BMW E/F series (Please Note PCF79XX adapter is optional)
Has the largest database of connection diagram
Reserve Ports: For future update
Supports Repair Porsche 12V lithium battery and BYD Lithium Battery (MC9S12XET256)
Supports EDC17/MED17 data calculation (checksum correction)
Support for third-party automatic HEX editing scripts
Supports Expert mode: batch write chips. vvdi prog only write a single chip at a time

Xhorse Multi-Prog Functions:

Read, Write and Clone ECU
BMW B48/B58 reading ISN
BMW MSD80/81 /85/87/MSV90
Mercedes-Benz SIM271
BMW MSV80
VW BOSCH MED17 Series ECU
BMW N13/N20/N55/B38/TC17X
Support Marelli, Siemens, Delphi and other ECU manufacturers

Read, Write and Clone TCU
Volkswagen Audi Skoda DQ200, DQ250, VL381 TCU etc.
Porsche DL501 TCU
Ford Dodge and other MPS6 series TCU
BMW DKG, Mercedes-Benz VCS and other models TCU

Vehicle Engine Data Calculation and Processing
MEDl 7/EDC17 data processing

Support Flexible Extension of Third-party Plug-ins
Support the development of third-party plug-ins and provide data processing and modification services

Read & Write MCU

Support reading and writing MCU of various brands including Renesas, Motolora, NXP, Infineon, etc.
Support certain encrypted chip reading and writing

Read & Write Vehicle Immo Module
Support Porsche, Land Rover, Mercedes-Benz EZS, VOLVO,
VW MQB dashboard, AUDI BCM2, etc.
Support modules including BMW EWS, CAS1 \CAS2\CAS3\CAS4+, FEM BDC, etc.
Support other common immo modules


Read & Write EEPROM
Support EEPROM and FLASH

Read & Write Vehicle Dashboard
Support dashboard of VW, Honda, Hyundai, Kia, etc.

VVDI Multi Prog Specifications:

Operating system: Linux
Processor: ZYNQ7020 Dual-core Cortex A9 +FPGA
Memory: 256M* 2 DDR+64M NOR FLASH
Display: 3.5-inch
Input voltage: 15V/4A
Working current: 300mA(14V)
Working temperatures: -20-50℃
Storage temperatures: -30-65℃
External interface: USB/RJ45
Dimensions: 233*150*54mm

Xhorse Multi Prog ECU and TCU List (Keep Updating)

ECU (Bench Mode)
VAG
1. SIMOS PCR2.1, EDC17c64
2. BOSCH: MG1CA811
3. BOSCH: MED17.1.6, MED17.1.21, MED17.1.61, MED17.5, MED1 7.5.1, MED1 7.5.2, MED1 7.5.5_TC1 766, MED1 7.5.5_TC1 767, MED1 7.5.20, MED1 7.5.21, MED1 7.5.25
4. BOSCH: EDC17C46, EDC17C74, EDC17CP24, EDC17CP44, EDC17CP54, EDC17U01, EDC17U05
5. BOSCH: MG1CS002一SPC5777, MD1 CP014_TC298TP, MG1 CS001_SPC5777, MG1 CS011 _SPC5777, MG1CS002_TC298TP, MD1 CP004_TC298TP, MD1 CP004一SPC5777, MG1 CS111 一SPC5777, MD1 CS004_TC298TP, MG1 CS008_SPC5777, MG1CS008_TC298TP
6. CONTINENTAL: SIMOS8.3x, SIMOS8.4x, SIMOS8.5x, SIMOS8.6X

BMW
1. CONTINENTAL: MSD80, MSV80, MSD81, MSD85, MSD87, MSV90
2. BOSCH: MD1CP002_SPC5777, MG1 CS003_SPC5777 (B48, B58), MG1 CS201 _TC298TP (B38, B48, B58), MD1CS001_TC298TP, MG1 CS024_TC298TP(B48, B58), MD1CP032_TC299
3. BOSCH: EDC1 7CP09_Fxx_TC1 796, EDC1 7C50_Exx, EDC1 7CP45_Exx, EDC17C06, EDC17C56
4. BOSCH: MEI 7.2.1
5. BOSCH: MEVD1 7.2.3, MEVD1 7.2_Fxx, MEVD1 7.2.4_Fxx(N20), MEVD1 7.2.6_Fxx, MEVD17.2.9_Exx, MEVD17.2.G, MEVD17.2.G (N55), MEVD17.2.H, MEVD1 7.2.6_Fxx, MEVD17.2.P_Fxx, MEVD17.2.K
6. OSCH: MEV17.2_TC1766, MEV1 7.2_TC1 767, MEV17.2_TC1796, MEV1 7.2.1

Mercedes Benz
1. CONTINENTAL: SIM271 DE, SIM271 KE
2. BOSCH: MEI 7.7, MED17.7.3.1, MED1 7.7.1, MED1 7.7.2, MED1 7.7.3, ME1 7.7.8
3. BOSCH: EDC17CP10, EDC17CP57, EDC17CP46, EDC17CP60
4. BOSCH: CRD3x.x_TC1793, CRD3x.x_TC1 797
5. BOSCH: MD1CP001-SPC5777, MG1 CP002_SPC5777, MD1CS006_TC298TP

GM
1. DELPHI: DCM3.7AP
2. DELCO: E37, E38, E39, E39A, E67, E78, E80, E82, E83, E83A, E83B, E84, E87, E92, E98

Nissan
1. DENSO: 23740-3Nxxx_Gen1 SH72531
2. BOSCH:EDC17C84

Hyundai/Kia
1. BOSCH: ME17.9.11, MEI 7.9.11.1
2. BOSCH:EDC17C53
3. BOSCH: MEG17.9.1 2_ECU

Ford
1. BOSCH: EDC17C70, EDC17CP65
2. BOSCH: ME17.0.3, ME17.8.5

Volvo
BOSCH: EDC17CP48, EDC1 7CP48_ver2, EDC1 7CP22

Other
1. AM_ME1 7.8.5,DOO_ME17.8.5
2. BOSCH: MG1CA007, MEI 7.8.8_TC1728, ME1 7.8.8_TC1 728_HW2, ME17.8.8_TC1 767, ME1 7.8.31, ME1 7.9.52
3. BOSCH: EDC1 7C55, EDC1 7C1 0, EDC1 7C1 0_TC1 796, EDC1 7C1 0_TC1 797, EDC1 7CP42, EDC1 7CP14, EDC17c81
4. BOSCH: MEVD1 7.8.4
5. BOSCH: MED17.8.1 0_TC1 728, MED17.8.1 0_TC1 728_Hw2, MED1 7.8.1 0_TC1 767
6. BOSCH: MD1 CS01 8, MG1 CS026_SPC58, MG1 CS032, MG1CS163, MD1CS01 2, MD1CS089, MD1CS069, MD1CS005_TC298TP, MG1 CS01 5_TC277TP, MG1 CS01 6_TC275TP, MG1CS01 7_TC277TP, MG1CS01 8, MG1CS019, MG1CS088
7. CONTINENTAL: SID208, SID209, SID211, SID807EVO ⑧ DENSO: KH, ZY, SH70xx_275xxx-xxx

ECU (Boot Mode)

VW series
1. SIMOS PCR2.1, EDC17c64
2. BOSCH: MED17.1.6, MED17.1.21, MED1 7.1.61, MED17.5, MED1 7.5.1, MED1 7.5.2, MED17.5.5_TC1 766, MED1 7.5.5_TC1 767, MED1 7.5.20, MED1 7.5.21, MED1 7.5.25
3. BOSCH: EDC1 7C46, EDC1 7C74, EDC1 7CP24, EDC1 7CP44, EDC1 7CP54, EDC17U01, EDC17U05
4. BOSCH: SIMOS8.3X, SIMOS8.4x, SIMOS8.5x, SIMOS8.6X

BMW series
1. CONTINENTAL: MSD80, MSV80, MSD81, MSD85, MSD87, MSV90
2. BOSCH: EDC1 7CP09_Fxx_TC1 796, EDC1 7C50_Exx, EDC17CP45_Exx, EDC17C06, EDC17C56
3. BOSCH: ME1 7.2.1
4. BOSCH: MEVD1 7.2.3.MEVD17.2_Fxx, MEVD1 7.2.4_Fxx(N20), MEVD1 7.2.6_Fxx, MEVD1 7.2.9_Exx, MEVD17.2.G, MEVD17.2.G(N55), MEVD17.2.H, MEVD1 7.2.6_Fxx, MEVD1 7.2.P_Fxx, MEVD1 7.2.K
5. BOSCH: MEV17.2_TC1766, MEV1 7.2_TC1 767, MEV17.2_TC1796, MEV1 7.2.1

Mercedes Benz series
1. CONTINENTAL: SIM271 DE,SIM271 KE
2. BOSCH: ME17.7, MED17.7.3.1, MED17.7.1, MED1 7.7.2, MED1 7.7.3, ME17.7.8
3. BOSCH: EDC17CP10, EDC17CP57, EDC17CP46, EDC17CP60
4. DELPHI: CRD2.x_MPC556x

Nissan series
BOSCH: EDC17C84

GM series
1. DELPHI: MT80.MT80.1
2. DELCO: E37, E38, E39, E39A, E67, E78, E80, E82, E83, E83A, E83B, E84, E87, E92, E98

Hyundai/Kia series
1. DELPHI: MT86
2. DELCO: DCM6.2AP

Other
1. CONTINENTAL: SID208, SID209, SID211, SID807EVO, SID310
2. SDI21.1 ,SDI21.2,SDI21.3
3. BOSCH: ME1 7.3.0
4. MARELLI: 8DF, MM10JA

TCU (Bench Mode)
VW
DL382, VL381, DL501 Genl, DL501 Gen2, DQ200Dxx, DQ200-G2, DQ200-G2_PQ, DQ200-MQB, DQ250-MQB, DQ250

Exx/Fxx BMW series
GETRAG DKG 436 Genl, GETRAG DKG 436 Gen2

Mercedes Benz series
VGS-FDCT, VGS2-FCVT, VGS2-FDCT

Ford series
1. ETRAG MPS6GETRAG
2. DPS6, DC4

TCU (Boot Mode)

Ford series
DPS6, DC4

Other
ZF 9HP

Multi-Prog Software Overview:
Language: English
Database update online

MultiProg Update Log:

Software V1.2.0.0, Database V25
2024.05.22
1. Added "Bosch number query" and "IMMO off" functions
2. Script: Added a function to get the current buffer data; optimized the code editor to support code folding and bracket matching
3. Fixed known issues

Software V1.1.5.0, Database V24

2024-05-20 21:01:28
* Fix the FAW BCM-3(MC9S12G128) option in ->
* Fix chip read exception problem in MPC556X and MPC555X series chip
* Fix the R7F701312 option failed to set the vibration frequency
* Fix the MC68HC711E9 and MC68HC11E9 option connection failure problem
* Fix some ME7.5 ECU connection failure problem and optimize the process
* Update the Great Wall air bag wiring diagram
+ The models of the read and write function modules that support Boot mode on the ECM are as follows：
1.VAG_CONTINENTAL_SIMOS18.3
+ Add R7F701331
option in
->->
+ Add ST72321AR6,
ST72321AR7,
ST72321AR9,
ST72321J7,
ST72321J9,
ST72321R6,
ST72321R7,
ST72321R9,
ST72521BAR6,
ST72521BAR9,
ST72521BM9,
ST72521BR6,
ST72521BR9,
ST72F321AR6,
ST72F321AR7,
ST72F321AR9,
ST72F321J7,
ST72F321J9,
ST72F321R6,
ST72F321R7,
ST72F321R9,
ST72F521AR6,
ST72F521AR9,
ST72F521M9,
ST72F521R6,
ST72F521R9
options in
->->
+ Add HC908EY16,
HC908GP32,
HC908GP32_UNLOCK_ERASE,
HC908JB16,
HC908JB16_UNLOCK_ERASE,
HC908QT1,
HC908QT2,
HC908QT4,
HC908QY1,
HC908QY2,
HC908QY4,
HC908Qxx_UNLOCK_ERASE options in ->-><mc68hc(9)08>
+ Add DELPHI_MT62.1 option in ->->
+ Add ACDelco GM E83 MPC5565 JTAG option in ->->
+ Add NETA U BCM(SPC5744B) option in ->->
+ Add W212 EPS(MC9S12XEG128) option in ->->
+ Add Cayenne Steering Gear (2018-)(SPC56EL60) option in->->
+ Add VOLKSWAGEN-STEERING-COLUMN(R7F701312)option in ->->
+ Add SERES AITO SF5 EPS option in ->->
 </mc68hc(9)08>

Software V1.1.5.0, Database V23

Database V23
2024-05-13 20:52:46
* Optimize the MAC7116 option read and write process
* Update the option R7F701330 wiring diagram
* Update the option GEELY-NL-3(R7F701A03) and GEELY-DNL-5(R7F701A03) wiring diagram
* Add STM32 series lock, unlock erase and encryption judgment functions
* Update all series wiring diagrams
* Add pic16f88x series EEPROM partition
* Update SPC563MXX series chip wiring diagram
+ The models of the read and write function modules that support Boot mode on the ECM are as follows：
1.VAG_CONTINENTAL_SIMOS18.1
2.VAG_CONTINENTAL_SIMOS18.6
3.VAG_CONTINENTAL_SIMOS18.7
+ Add TC27X-40F, TC27X-40F(JTAG) options
+ Add MC9S12KL64_SECURED,
MC9S12KL64_UNSECURED,
MC9S12KL128_SECURED,
MC9S12KL128_UNSECURED,
MC9S12XDG256_SECURED,
MC9S12XDG256_UNSECURED,
MC9S12XDG512_SECURED,
MC9S12XDG512_UNSECURED options
+ Add MC68HC912DT128C_SECURED,
MC68HC912DT128C_UNSECURED,
MC68HC912DG128C_SECURED,
MC68HC912DG128C_UNSECURED,
MC68HC912DG128P_SECURED,
MC68HC912DG128P_UNSECURED,
MC68HC912DJ128A_SECURED,
MC68HC912DJ128A_UNSECURED,
MC68HC912D60C_SECURED,
MC68HC912D60C_UNSECURED,
MC68HC912D60P_SECURED,
MC68HC912D60P_UNSECURED options
+ Add HC908KX2, HC908JL16, HC908JL16_UNLOCK_ERASE, HC908JL8 options
+ Add MC9RS08KA1, MC9RS08KA2, MC9RS08KA4, MC9RS08KA8, MC9RS08LA8 options
+ Add MC68HC05B6(0B91T), MC68HC05B8, MC68HC05B16, MC68HC705B32 options
+ Add LONKING_FORKLIFT_INSTRUMENT(PIC16F887) option
+ Add NFINITI Q50(MC9S12XEP100_UNSECURED)  option
+ Add Trumpchi GS3 POWER AIRBAG(R7F701A03)-LOCK-READ, Trumpchi GS3 POWER AIRBAG(R7F701A03)-LOCK-WRITE options
+ Add Monjaro AIRBAG(R7F701330)-LOCK-READ, Monjaro AIRBAG(R7F701330)-LOCK-WRITE options
+ Add Geely Radorsensor(0N72D) option <mc68hc(9)12><mc68hc(9)08><mc68hc(7)05></mc68hc(7)05></mc68hc(9)08></mc68hc(9)12>

Database V22
2024-05-06 21:27:33
* Fix some issues with 9S12XE options
* Fix the CFLASH read/write exception of MPC574XX series options

Database V21
2024-05-06 10:35:55
* The AM29FXXX series adds a temporary unblock protection function
* Update the option SONATA(2009-2010)(S29CDO16J) wiring diagram in ->
* Fixed the EMS6104(AM29F400BB) option to erase the exception problem in ->
* Fixed bugs in TC2XX(JTAG) options in ->
* Repair ROEWE BMS(MPC5607B)read exception problem in ->->
* Repair MPC5605B option wiring picture in ->->
* Update the option CS75-AIRCONDITION-MODULE(2014) wiring diagram in ->
* Fixed the 523-AIRBAG option exception problem in ->
* Optimize the MAC7241 and MAC7242 options process in ->->
* Fixed some MC9S12 chip and module options verification failure
* Update some options wiring diagram in ->->
* Add the function of security status judgment in ->->
* Fixed the MB91F526 connection failure problem in ->->
+ The models of the read and write function modules that support Bench and Boot mode on the ECM are as follows:
1.VAG_CONTINENTAL_SIMOS12.1
2.VAG_CONTINENTAL_SIMOS12.2
+ Add R7F701333A option in ->->
+ Add MPC5673K, MPC5674K, MPC5675K options in ->->
+ Add TC27X-64F option in ->->
+ Add BYD ECU CONTROL MODULE(TB30) option in ->->
+ Add TIGUAN Navigation Module(STM8S207CBT6) option in ->->
+ Add TOYOTA Sensor Steering(CY96F636R) option in ->->
+ Add Feidi Dito BCM(STMAF5289) option in ->->
+ Add BAOJUN 730 BCM(D70F3628)-LOCK-READ, BAOJUN 730 BCM(D70F3628)-LOCK-WRITE options in ->->

+ Add MAGOTAN Audio AMP  option in  ->->

Software V1.1.3.0, Database V12

2024-03-18 11:30:10
* Some options wiring diagrams increase pull-up resistance
* Added chip id identification for some options
* Added the boot wiring diagram of FCA_MARELLI_9DF in ECU
* The processing flow of PSA_DELPHI_DCM6.2A etc. is optimized in ECU
* Fix MC9S12XE partition some bugs.
* Repair Tesla battery(MM9Z1J638)  option in ->
* Modify FORD-ECU(AM29BDD160GB) option in ->
* Modify HYUNDAI(2005-2008)(AM29BDD160GB), SONATA(2009-2010)(S29CDO16J) options in ->
* Modify KIA(2005-2008)(AM29BDD160GB) option in ->
+ The models of the read and write function modules that  support Boot mode on the ECM are as follows:
RENAULT_CONTINENTAL_SID309, PSA_DELPHI_DCM7.1A
+ The models of the read and write function modules that  support Bench mode on the ECM are as follows：
Alfa Romeo:
1.FCA_MARELLI_MM10JA

FIAT:
1.FAL_MARELLI_6JF,FAL_MARELLI_6F3
+ Add MC9S12UF32_UNSECURED  option in  ->->
+ Add MC68HC05E6(0G72G), MC68HC05E6(0F82B) options in  ->-><mc68hc(7)05>
+ Add STM32F103x8 option in ->->
+ CR16MCS9V, CR16MCT9V options in  ->->
+ Add CEM_R5F64524_KFD, CEM_R5F64525_KFD  options in ->
+ Add MQB48-LOCK(R7F701401)-WRITE,
MQB48-LOCK(R7F701402)-WRITE,
MQB48-LOCK(R7F701407)-WRITE
options in ->->
+ Add MALIBU AIRBAG(2014)(SPC56AP54) option in ->
+ Add P5.0NA_WRITE(UART),
P5.0NA_READ(AUD),
P5.0SC_WRITE(UART),
P5.0SC_READ(AUD)
options in ->->
+ Add S3000_READ(AUD), S3000_WRITE(UART) options in ->->
+ Add PORSCHE Lithium Battery(MM9Z1J638)  option in  ->
+ Add AION-S BMS BOX(SPC5746R) option in  ->->
+ Add GL8 Keyless Module(SPC5602D) option in  -></mc68hc(7)05>

Package List:
1pc x power cable
1pc x MCU DB15 cable
1pc x USB cable
1pc x Main unit + VH13 adapter
1pc x Power adapter
1pc x MCU cable
1pc x ECU cable
1pc x VH24 interface adapter board
1pc x VH20 interface adapter board
1pc x OBD cable
1pc x ECU DB15 cable
43pcs x ECU harness plug replacement parts
